| 品牌：RICHWAVE | 型号：RTC670*** | 类型：稳压IC |
| 封装：SOP | 功率：2W | 特色服务：有 |
代理台湾立积无线图传专用射频芯片RTC670*** RTC6715
并提供RTC670***参考设计原理图
RTC6705 CMOS 5.8GHz Band FM Transmitter Product Description The RTC6705 is a wide-band FM transmitter intended for the application on 5.8GHz bands FM transmission. This chip includes a 5.8GHz band RF modulator, two channels of audio modulator and internal power amplifier with +13dBm power output referred to external matching network. The 5.8GHz band RF modulator block, which is frequency-synthesizer based with an integrated VCO, generates the 5.8GHz band FM signal modulated with video signal and two modulated audio subcarriers at 6MHz and 6.5MHz respectively. Both Stereo and Mono application are available on the chip. Transmission frequency can be set by internal register via SPI programming, or by selecting six dedicated pins. Two stages output power of +2dBm or +13dBm can be configured via pins 34 and 35. Both CE and FCC regulations are easy to pass by using RTC6705 with application circuit and single room shielding case. Features 3.3V power supply Built-in PA with +13dBm output power 5.8GHz band FM modulator and transmitter Simple digital pins setting 24 fixed channels to eliminate external micro-controller Two audio subcarrier modulators at 6MHz/6.5MHz Single chip CMOS technology with integrated VCO and PLL Transmitter frequency programmability by SPI 40-pin leadless QFN package pass RoHS Application AV Sender Baby Monitor Wireless Camera Wireless Audio Wireless Earphone
Wireless Video/Audio
RichWave 代理 立积全系列型号offers a complete product line of Wireless Video/Audio Transmission chipsets for different ISM bands (2.4GHz and 5.8GHz).
Richwave’s Analog chipsets transmit and receive CVBS signals with very low distortion and latency, providing excellent video and audio quality.
Richwave’s High Data Rate (HDR) Frequency Hopping Transceivers provide excellent transmission distance and anti-interference features, easily interfacing with other multimedia ICs, such as MJPEG, MPEG4, and H.264 chipsets, to transmit the encoded video/audio content.
Digital Wireless Transceiver
| Part No. | Freq (Ghz) | Modulation | Anti-jamming | Package (mm, typ) | 3rd Party Codec | Vendor | Applications | Performance |
|---|---|---|---|---|---|---|---|---|
| RTC6763S | 2.4 | BPSK QPSK 16QAM | FHSS | 40L QFN 6.0x6.0x0.85 | GPL327902B GPL32611B | Generalplus (MJPEG) | Backup Camera Surveillance | 4.3"LCD, 480x272, 20~30 fps 5"LCD, 800x480, 10 fps |
| GM8136 GM8286 | Grain Media (H.264) | Surveillance | 7"/10.1"LCD, 1024x600, 4T1R 720p: >20 fps 1080p: 15 fps | |||||
| SNCC70 SNCC71 | Sonix (H.264) | Backup Camera | 4.3"/5"/7" LCD, 800x480 7"/10.1"LCD, 1024x600 1T1R: 1080P, 20~30 fps 4T1R: 640x480, >15 fps |
Analog Wireless Audio/ Video
| Part No. | Transmitter | Receiver | Freq. (GHz) | Modulation | Package (mm, typ) | Applications |
|---|---|---|---|---|---|---|
| RTC6701 | V | 2.4 | FM/FSK | 32L QFN 5.0x5.0x0.85 | AV Sender, Backup Camera, Drone | |
| RTC6711 | V | 2.4 | FM/FSK | 48L QFN 7.0x7.0x0.85 | AV Sender, Backup Camera, Drone | |
| RTC6705 | V | 5.8 | FM | 40L QFN 6.0x6.0x0.85 | AV Sender, Backup Camera, Drone | |
| RTC6715 | V | 5.8 | FM | 48L QFN 7.0x7.0x0.85 | AV Sender, Backup Camera, Drone |
Wireless Audio/Video
| Part No. | Description | |
|---|---|---|
| RTC6701 | 2.4GHz FM/FSK Transmitter |  |
| RTC6711 | 2.4GHz FM/FSK Receiver | |
| RTC6705 | 5.8GHz FM Transmitter | |
| RTC6715 | 5.8GHz FM Receiver | |
| RTC6763S | 2.4GHz ISM Band FH Transceiver |
