| 产品特性：MCU | 品牌：TI | 型号：MSP430F437 |
| 类型：单片机 | 封装：TSSOP | 系列：MSP430G |
| 批号：2018+ | 产品说明：单片机 | 货号：20+ |
| 是否跨境货源：否 | 包装：reel | 应用领域：家用电器 |
TI 代理MCU现货供应， MSP430F437 449 价格咨询 18820954295
MSP430G2x32、MSP430G2x02 MSP430G2001 MSP430F479 MSP430G2221 混合信号微处理器
产品详细信息
参数
封装|引脚|尺寸
特性
描述
技术文档
The Texas Instruments MSP430 family of ultra-low-power microcontrollers consist of several devices featuring different sets of peripherals targeted for various applications. The architecture, combined with five low-power modes is optimized to achieve extended battery life in portable measurement applications. The device features a powerful 16-bit RISC CPU, 16-bit registers, and constant generators that contribute to maximum code efficiency. The digitally controlled oscillator (DCO) allows wake-up from low-power modes to active mode in less than 1 ?s.
The MSP430G2x32 and MSP430G2x02 series of microcontrollers are ultra-low-power mixed signal microcontrollers with built-in 16-bit timers, and up to 16 I/O capacitive-touch enabled pins and built-in communication capability using the universal serial communication interface. The MSP430G2x32 series have a 10-bit A/D converter. For configuration details, see . Typical applications include low-cost sensor systems that capture analog signals, convert them to digital values, and then process the data for display or for transmission to a host system.
特性
Low Supply Voltage Range: 1.8 V to 3.6 V
Ultra-Low Power Consumption
Active Mode: 220 ?A at 1 MHz, 2.2 V
Standby Mode: 0.5 ?A
Off Mode (RAM Retention): 0.1 ?A
Five Power-Saving Modes
Ultra-Fast Wake-Up From Standby Mode in Less Than 1 ?s
16-Bit RISC Architecture, 62.5-ns Instruction Cycle Time
Basic Clock Module Configurations
Internal Frequencies up to 16 MHz With Four Calibrated Frequencies
Internal Very-Low-Power Low-Frequency (LF) Oscillator
32-kHz Crystal
External Digital Clock Source
One 16-Bit Timer_A With Three Capture/Compare Registers
Up to 16 Capacitive-Touch Enabled I/O Pins
Universal Serial Interface (USI) Supporting SPI and I2C
10-Bit 200-ksps Analog-to-Digital (A/D) Converter With Internal Reference, Sample-and-Hold, and Autoscan (MSP430G2x32 Only)
Brownout Detector
Serial Onboard Programming, No External Programming Voltage Needed, Programmable Code Protection by Security Fuse
On-Chip Emulation Logic With Spy-Bi-Wire Interface
Package Options
TSSOP: 14 Pin, 20 Pin
PDIP: 20 Pin
QFN: 16 Pin
All trademarks are the property of their respective owners.
查看更多MSP430G2332内容， 可以添加群主的微信 18820954295， 也可以免费申请样品
