| 品牌：SGMICRO | 型号：SGM3756YTDI6G | 类型：稳压IC |
| 封装：SOP | 系列：SGM4 | 产品说明：TRANSLATOR |
| 货号：19+ | 是否跨境货源：否 | 包装：REEL |
| 应用领域：3C数码 |
圣邦微SGMICRO代理SGM3756YTDI6G
S
GENERAL DESCRIPTION
With a 40V rated integrated switch FET, the SGM3756 is a boost converter that drives LEDs in series. The boost converter has a 40V, 1.*** internal MOSFET; thus it can drive single or parallel LED strings for small to large size panel backlighting.
The default white LED current is set with the external sensor resistor, RSET, and the feedback voltage is regulated to 200mV, as shown in the typical application. During the operation, the LED current can be controlled by using a pulse width modulation (PWM) signal applied to the CTRL pin, through which the duty cycle determines the feedback reference voltage. The SGM3756 does not burst the LED current; therefore, it does not generate audible noises on the output capacitor. For maximum protection, the device features integrated open LED protection that disables the SGM3756 to prevent the output voltage from exceeding the IC absolute maximum voltage ratings during open LED conditions.
The SGM3756 is available in a Green TDFN-2×2-6L package. It operates over an ambient temperature range of -40℃ to +85℃.
PIN CONFIGURATIONS
FEATURES
1:250 Stable Luminance Dimming
Low EMI by Conducting Ringing Cancelling
Improved PSRR for Waveless Lighting
Input Voltage Range: 2.7V to 5.5V
Integrated 40V, 1.*** Current Limit MOSFET
38V Open LED Protection for 10 LEDs in Series
1.2MHz Switching Frequency
200mV Reference Voltage
PWM Brightness Control
Under-Voltage Protection
Up to 90% Efficiency
Built-in Soft-Start Function
Thermal Shutdown
-40℃ to +85℃ Operating Temperature Range
Available in a Green TDFN-2×2-6L Package
APPLICATIONS
Smart Phone Backlighting
Tablet Backlighting
PDAs, Handheld Computers, GPS Receivers
Portable Media Players, Portable TVs
White LED Backlighting for Small and Media Form Factor Displays
ORDERING INFORMATION
