圣邦微代理sgm62110S  3A电流的升降压一体电源芯片，***静态电流20UA

The SGM62110 and SGM62111 are 4-switch Buck-Boost converters with programmable I2C interface for simple configuration of integrated rich features. Synchronous rectification improves system efficiency which is friendly for battery operated applications. In addition, the programmable light load PFM (pulse frequency modulation) mode and low quiescent current offer above 90% efficiency in the 10mA to 2A output current range.

The SGM62110 and SGM62111 are capable to regulate the output voltage when the input voltage is below, above or equal to the output voltage. The mode transition is also optimized to ensure smooth operation and reduce output voltage ripple.

Dynamic voltage scaling is enabled via VSEL pin and I2C controlled output voltage registers which allows the device to toggle output voltages based on application needs.

The SGM62110 and SGM62111 implement robust protection features such as over-temperature, input over-voltage and output over-current protections to protect device against unexpected system failure.

The SGM62110 and SGM62111 are available in a small Green WLCSP-2.21×1.40-15B package. High integration provides a compact solution with only four external components, allowing implementation in a PCB area as small as 39mm2.

FEATURES

• 2.2V to 5.5V Input Voltage Range

• 1.8V to 5.2V Output Voltage Range



  2.2A Output Current for VIN ≥ 2.5V, VOUT = 3.3V

  2.*** Output Current for VIN ≥ 2.8V, VOUT = 3.5V

  3.0A Output Current for VIN ≥ 3.0V, VOUT = 3.5V

  2A Output Current for VIN ≥ 2.5V, VOUT = 3.5V

• 3.3V or 3.45V Pre-Programmed Output Voltage

• Above 90% Efficiency for IOUT from 10mA to 2A

• 18μA (TYP) Quiescent Current

• User-Selectable PFM Mode

• Real Buck, Boost and Buck-Boost Modes

• Automatic Mode Transition

• I?C Interface (Up to 1MHz Clock Speed)

• Internal Soft-Start

• OTP, Input OVP and Output OCP

• True Shutdown Function with Load Disconnect and Active Output Discharge

• Available in a Green WLCSP-2.21×1.40-15B Package

APPLICATIONS

Smartphones and Tablets

Pre-regulators and USB VCONN Supplies

TWS Earbud Chargers

General-Purpose Point

The SGM62110S is a 4-switch Buck-Boost converter with programmable I2C interface for simple configuration of integrated rich features. Synchronous rectification improves system efficiency which is friendly for battery operated applications. In addition, the programmable light load PFM (pulse frequency modulation) mode and low quiescent current offer above 90% efficiency in the 10mA to 2A output current range.

The SGM62110S is capable to regulate the output voltage when the input voltage is below, above or equal to the output voltage. The mode transition is also optimized to ensure smooth operation and reduce output voltage ripple.

Dynamic voltage scaling is enabled via VSEL pin and I2C controlled output voltage registers which allows the device to toggle output voltages based on application needs.

The SGM62110S implements robust protection features such as over-temperature, input over-voltage and output over-current protections to protect device against unexpected system failure.

The SGM62110S is available in a small Green WLCSP-1.47×2.21-15B package. High integration provides a compact solution with only four external components, allowing implementation in a PCB area as small as 39mm2 .

FEATURES

• 2.2V to 5.5V Input Voltage Range

• 1.8V to 5.2V Output Voltage Range

• Minimal Load Current Capability:
  2.*** Output Current for VIN ≥ 2.5V, VOUT = 3.3V
  3.0A Output Current for VIN ≥ 3.0V, VOUT = 3.3V
  2.0A Output Current for VIN ≥ 2.5V, VOUT = 3.5V
  1.*** Output Current for VIN ≥ 3.5V, VOUT = 5V

• 3.3V or 3.45V Pre-Programmed Output Voltage

• High Efficiency Performance
  Above 90% for IOUT from 10mA to 2A

• 22μA (TYP) Quiescent Current

• User-Selectable PFM Mode

• Real Buck, Boost and Buck-Boost Modes

• Automatic Mode Transition

• I?C Interface (Up to 1MHz Clock Speed)
  Compatible with 3.3V and 1.8V I/O Logic

• Internal Soft-Start

• OTP, Input OVP and Output OCP

• True Shutdown Function with Load Disconnect and Active Output Discharge

• Available in a Green WLCSP-1.47×2.21-15B Package

APPLICATIONS

Smartphones and Tablets
Pre-regulators and USB VCONN Supplies
TWS Earbud Chargers
General-Purpose Point-of-Load Re

he SGM62110 is a high-efficiency, synchronous step-down DC-DC converter from SG Micro Corp (SGMICRO). Here are its key features:

Key Specifications:

• Input Voltage Range: 4.5V to 36V

• Output Voltage Range: Adjustable down to 0.6V

• Output Current: Up to 1A

• Switching Frequency: 2.2MHz (fixed)

• Efficiency: Up to 95% (depends on load & conditions)

• Operation Mode: PWM (Pulse Width Modulation)

• Protections:

• Overcurrent protection (OCP)

• Thermal shutdown

• Undervoltage lockout (UVLO)

• Package: TSOT-23-6 (small form factor)

Typical Applications:

• Industrial & automotive systems

• Battery-powered devices

• Networking equipment

• Distributed power supplies

Advantages:

• Wide input voltage range (good for 12V/24V systems)

• High efficiency at light and heavy loads

• Compact package for space-constrained designs

Alternatives (if unavailable):

• TPS62110 (TI)

• LMR33610 (TI)

• MP2307 (MPS)
